Product Summary
The 400CNQ045 is a Schottky Rectifier. The 400CNQ045 center tap, high current, Schottky rectifier module series has been optimized for very low forward voltage drop, with moderate leakage. The proprietary barrier technology allows for reliable operation up to 150℃ junction temperature. Typical applications are in switching power supplies, converters, freewheeling diodes, welding, and reverse battery protection.
Parametrics
400CNQ045 absolute maximum ratings: (1) Maximum average forward current: 200 A; (2)Maximum peak one cycle non-repetitive surge current per leg: 3400 A; (3)Non-repetitive avalanche energy per leg: 180 mJ; (4)Repetitive avalanche current per leg: 40 A.
Features
400CNQ045 features: (1)150 ℃ TJ operation; (2)Center tap module; (3)Very low forward voltage drop; (4)High frequency operation; (5)Guard ring for enhanced ruggedness and long term reliability; (6)Lead (Pb)-free; (7)Designed and qualified for industrial level.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 400CNQ045 |
|
DIODE SCHOTTKY 45V 200A TO-244AB |
Data Sheet |
Negotiable |
|
||||
|
400CNQ045PbF |
Other |
|
Data Sheet |
Negotiable |
|
||||
