MBRS140T3G

MBRS140T3G, surface mount schottky power rectifier, 40 V, 1.0 A, 60 Hz, DO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.05~0.10 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.10 / Piece
1000 ~ 10000 :	0.08 / Piece
10000 ~ 100000 :	0.05 / Piece

PartNumber:: MBRS140T3G

Brand:: ON Semiconductor - ON | D/C: 13+

Availability:: Supply Ability: 1000000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-30

From Other Seller

Part Number:MBRS140T3G
US $0.05 - 0.10
Quantity:

piece

Product Summary

The MBRS140T3G is a surface mount schottky power rectifier. The MBRS140T3G employs the use of the schottky barrier principle in a large area metal.to.silicon power diode. State-of-the-art geometry of the MBRS140T3G features epitaxial construction with oxide passivation and metal overlay contact. Ideally suited for low voltage, high frequency rectification, or as free wheeling and polarity protection diodes in surface mount applications where compact size and weight are critical to the system.

Parametrics

MBRS140T3G absolute maximum ratings: (1)Peak repetitive reverse voltage: 40V; (2)Working peak reverse voltage: 40V; (3)DC blocking voltage: 40V; (4)Average rectified forward current TL = 115℃ IF(AV): 1.0A; (5)Non repetitive peak surge current (surge applied at rated load conditions halfwave, single phase, 60 Hz) ifsm: 40A; (6)Operating junction temperature TJ: -65 to +125℃.

Features

MBRS140T3G features: (1)Small compact surface mountable package with J-bend leads; (2)Rectangular package for automated handling; (3)Highly stable oxide passivated junction; (4)Very low forward voltage drop (0.55 V Max @ 1.0 A, TJ = 25℃); (5)Excellent ability to withstand reverse avalanche energy transients; (6)Guardring for stress protection; (7)Pb-free package is available.
