Product Summary

The 6MBI150FA is an IGBT module. The applications of it include Inverter for motor drive, AC.DC servo drive amplifier, Uninterruptible power supply, Industrial machines, such as welding machines.

Parametrics

6MBI150FA absolute maxing ratings: (1)VCES: 600V; (2)VGES: ±20V; (3)IC: 150A; (4)IC pulse: 300A; (5)-IC: 150A; (6)-IC pulse: 300A; (7)Pc: 450W; (8)Tj: +150℃; (9)Tstg: -40~+125℃; (10)m: 450g; (11)Viscl: 2500V; (12)Mounting*1: 3.5N.m; (13)Terminal*1: 3.5N.m.

Features

6MBI150FA features: (1)Low saturation voltage; (2)Voltage drive; (3)Variety of power capacity series.

Diagrams

6MBI150FA block diagram
