Product Summary

The FZ300R12KS4 is a transistor.

Parametrics

FZ300R12KS4 absolute maximum ratings: (1)Isolated Case (Y/N): Yes; (2)Circuits Per Package: 1; (3)V(BR)CES (V): 1.2k; (4)V(BR)GES (V): 20; (5)I(C) Max. (A): 300; (6)Absolute Max. Power Diss. (W): 2.0k; (7)Minimum Operating Temp (℃): -40; (8)Maximum Operating Temp (℃): 150; (9)Thermal Resistance Junc-Case: 200m; (10)I(CES) Min. (A): 6.0m.

Features

FZ300R12KS4 features: (1)@V(CES) (V) (Test Condition): 1.2k; (2)I(GES) Max. (A): 40u; (3)@V(GES) (V) (Test Condition): 20; (4)V(CE)sat Max. (V): 4.0; (5)@I(C) (A) (Test Condition): 300; (6)@V(GE) (Test Condition): 15; (7)V(GE)th Max. (V): 6.0; (8)@I(C) (A) (Test Condition): 300m; (9)@V(CE) (V) (Test Condition): 5.0; (10)t(f) Max. (s) Fall time.: 300n; (11)Package Style: MODULE-var.

Diagrams

FZ300R12KS4 block diagram
