Product Summary

The SF100BA50 is a isolated power MOSFET module designed for fast swiching applications of high voltage and current. The mounting base of the module is electrically isolated from semiconductor elements for simple heatsink construction. The applications are UPS CVCF , Motor Control, Switching Power Supply, etc.

Parametrics

SF100BA50 absolute maximum ratings: (1)VDSS, Drain-Source Voltage: 500 V; (2)VGSS, Gate-Source Voltage: 20 V; (3)ID, Drain Current, DC: Duty 43% 100A; Pulse, IDP: 200A; (4)ID, Reverse Drain Current: 100 A; (5)PT, Total Power Dissipation: 600 W; (6)Tj, Channel Temperature: -40 to 150°C; (7)Tstg, Storage Temperature: -40 to 125°C; (8)VISO, Isolation Voltage R.M.S. A.C. 1minute: 2500 V.

Features

SF100BA50 features: (1)ID=100A,VDSS=500V; (2)Suitable for high speed switching applications; (3)Low ON resistance; (4)Wide Safe Operating Areas; (5)trr 700ns.

Diagrams

SF100BA50 block diagram
