Product Summary

The cm400hu-24f is a high power switching. Applications of the cm400hu-24f include: General purpose inverters & Servo controls, etc.

Parametrics

cm400hu-24f absolute maximum ratings: (1) Collector-emitter voltage VCES: 1200V (G-E Short) ; (2) Gate-emitter voltage VGES: ±20V (C-E Short) ; (3) Collector current IC: 400A (Tc=25°C) , 800A (Pulse) ; (4) Emitter current IE: 400A (TC=25°C) ,IEM: 800A (Pulse) ; (5) Maximum collector dissipation Pc: 1600W (Tc=25°C) ; (6) Junction temperature Tj: -40 to +150°C; (7) Storage temperature Tstg: -40 to +125°C; (8) Storage temperature Viso: 2500V (Main terminal to base plate, AC 1 min.) .

Features

cm400hu-24f features: (1) IC: 400A; (2) VCES: 1200V; (3) Insulated Type; (4) 1-elements in a pack.

Diagrams

CM400HU-24F Circuit Diagram
