Product Summary

The CM100DK-24E is an IGBT module. Applications are (1)General purpose inverters; (2)Servo controls, etc.

Parametrics

CM100DK-24E absolute maximum ratings: (1)Collector-emitter voltage, G-E short, VCES: 1200V; (2)Gate-emitter voltage, C-E short, VGES: ±20V; (3)Collector current, DC, TC= 108℃, IC: 100A; (4)Collector current, pulse, ICM: 200A; (5)Emitter current, operation, IE: 100A; (6)Emitter current, pulse, IEM: 200A; (7)Maximum collector dissipation, TC= 25℃, PC: 960W; (8)Junction temperature, TJ: -40 to +150℃; (9)Storage temperature, Tstg: -40 to +125℃; (10)Isolation voltage, Viso: 3500V.

Features

CM100DK-24E features: (1)IC: 100A; (2)VCES: 1700V; (3)Insulated type; (4)2-elements in a pack.

Diagrams

CM100DK-24E pin connection
