OP37AZ

OP37AZ, Operational Amplifier, CDIP, 22V, 25mA, Advanced Crystal Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $15.00~20.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	20.00 / Piece
11 ~ 100 :	18.00 / Piece
101 ~ 1000 :	15.00 / Piece

PartNumber:: OP37AZ

Brand:: Analog Devices - ADI | Pack: DIP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-31

From Other Seller

Part Number:OP37AZ
US $15.00 - 20.00
Quantity:

piece

Product Summary

The OP37AZ is a low noise, precision, high speed operational amplifier. The OP37AZ provides the same high performance as the OP27, but the design is optimized for circuits with gains greater than five. This design change increases slew rate to 17 V/μs and gain-bandwidth product to 63 MHz. The OP37AZ provides the low offset and drift of the OP07 plus higher speed and lower noise. Offsets down to 25 μV and drift of 0.6 μV/℃ maximum make the device ideal for precision instrumentation applications. Exceptionally low noise (en= 3.5 nV/ @ 10 Hz), a low 1/f noise corner frequency of 2.7 Hz, and the high gain of 1.8 million, allow accurate high-gain amplification of low-level signals.

Parametrics

OP37AZ absolute maximum ratings: (1)Supply Voltage: 22 V; (2)Internal Voltage: 22 V; (3)Output Short-Circuit Duration: Indefinite; (4)Differential Input Voltage: 0.7 V; (5)Differential Input Current: 25 mA; (6)Storage Temperature Range: -65℃ to +150℃; (7)Operating Temperature Range: -40℃ to +85℃; (8)Lead Temperature Range (Soldering, 60 sec): 300℃; (9)Junction Temperature: -45℃ to +150℃.

Features

OP37AZ features: (1)Low Noise, 80 nV p-p (0.1 Hz to 10 Hz) 3 nV/√Hz @ 1 kHz; (2)Low Drift, 0.2 V/ C; (3)High Speed, 17 V/ s Slew Rate 63 MHz Gain Bandwidth; (4)Low Input Offset Voltage, 10 V; (5)Excellent CMRR, 126 dB (Common-Voltage @ 11 V); (6)High Open-Loop Gain, 1.8 Million; (7)Replaces 725, OP-07, SE5534 In Gains > 5; (8)Available in Die Form.
