MAX3232EIDBR

MAX3232EIDBR, True RS-232 Transceiver, 16-DIP, 6V, 1mA, Maxim Integrated

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: MAX3232EIDBR

Brand:: Texas Instruments - TI | Pack: SSOP | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-31

From Other Seller

Part Number:MAX3232EIDBR
US $0.30 - 0.50
Quantity:

piece

Product Summary

The MAX3232EIDBR is a true RS-232 Transceiver. The MAX3232EIDBR +3.0V-powered EIA/TIA-232 and V.28/V.24 communications interface device features low power consumption, high data-rate capabilities, and enhanced electrostatic-discharge (ESD) protection. The enhanced ESD structure protects all transmitter outputs and receiver inputs to ±15kV using IEC 1000-4-2 Air-Gap Discharge, ±8kV using IEC 1000-4-2 Contact Discharge (±9kV for MAX3232EIDBR), and ±15kV using the Human Body Model. The logic and receiver I/O pins of the MAX3232EIDBR are protected to the above standards, while the transmitter output pins are protected to ±15kV using the Human Body Model. The applications of the MAX3232EIDBR include battery-powered, equipment printers, cell phones smart phones, cell-phone data, cables xDSL modems, notebook, subnotebook, and palmtop computers.

Parametrics

MAX3232EIDBR absolute maximum ratings: (1)VCC to GND: -0.3V to +6V; (2)V+ to GND: -0.3V to +7V; (3)V- to GND: +0.3V to -7V; (4)V+ + |V-|: +13V; (5)Input Voltages, T_IN, EN, SHDN, MBAUD to GND: -0.3V to +6V; R_IN to GND: ±25V; (6)Output Voltages, T_OUT to GND: ±13.2V; (7)Short-Circuit Duration, T_OUT to GND: Continuous; (8)Continuous Power Dissipation (TA = +70℃): 16-Pin SSOP (derate 7.14mW/℃): 571mW; 16-Pin Wide SO (derate 9.52mW/℃): 762mW; 18-Pin Wide SO (derate 9.52mW/℃): 762mW; 18-Pin PDIP (derate 11.11mW/℃): 889mW; 20-Pin TSSOP (derate 10.9mW/℃): 879mW; 20-Pin SSOP (derate 8.00mW/℃): 640mW; 28-Pin SSOP (derate 9.52mW/℃): 762mW; 28-Pin Wide SO (derate 12.50mW/℃): 1W; 28-Pin TSSOP (derate 12.8mW/℃): 1026mW; 32-Lead QFN (derate 23.2mW/℃): 1860mW; 6 x 6 UCSP (derate 12.6mW/℃): 1010mW; (9)Operating Temperature Ranges: 0℃ to +70℃; (10)Storage Temperature Range: -65℃ to +150℃; (11)Lead Temperature (soldering, 10s): +300℃; (12)Bump Reflow Temperature, Infrared, 15s: +200℃; Vapor Phase, 20s: +215℃.

Features

MAX3232EIDBR features: (1)ESD Protection for RS-232 I/O Pins: ±15kV—Human Body Model; ±8kV—IEC 1000-4-2, Contact Discharge; ±15kV—IEC 1000-4-2, Air-Gap Discharge; (2)Guaranteed Data Rate 250kbps; (3)Latchup Free; (4)Low-Power Shutdown with Receivers Active: 1μA; (5)Meets EIA/TIA-232 Specifications Down to +3.0V.
