Product Summary

The MUR20040CT is a Schottky barrier rectifier.

Parametrics

MBRP20060CT absolute maximum ratings: (1)Peak repetitive reverse voltage working peak reverse voltage DC blocking voltage VRRM VRWM VR: 60 Volts; (2)Average rectified forward current per device (rated VR)TC = 140°C IF(AV): 200 Amps,per leg: 100 Amps; (3)Peak repetitive forward current, per leg (rated VR, square wave, 20 kHz), TC = 140°C IFRM: 200 Amps; (4)Non–repetitive peak surge current (surge applied at rated load conditions halfwave, single phase, 60 Hz)IFSM: 1500 Amps; (5)Peak repetitive reverse current, per leg (2.0 ms, 1.0 kHz)see figure 6. IRRM: 2.0 Amps; (6)Operating junction temperature TJ: -55 to +175 °C; (7)Storage temperature Tstg: -55 to +150 °C; (8)Voltage rate of change (rated VR)dv/dt: 10000 V/ms.

Features

MBRP20060CT features: (1)Dual diode construction — may be paralleled for higher current output; (2)Guardring for stress protection; (3)Low forward voltage; (4)175°C operating junction temperature; (5)Guaranteed reverse avalanche.

Diagrams

MBRP20060CT pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MBRP20060CT
MBRP20060CT

ON Semiconductor

Schottky (Diodes & Rectifiers) 200A 60V

Data Sheet

Negotiable
MBRP20060CTG
MBRP20060CTG

ON Semiconductor

Schottky (Diodes & Rectifiers) 200A 60V

Data Sheet

Negotiable
