2N3904

2N3904, NPN general purpose amplifier, 100 MHz, 40 V, 200 mA, TO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: 2N3904

Brand:: Fairchild Semiconductor - Fairchild | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-17

From Other Seller

Part Number:2N3904
US $0.30 - 0.50
2N3904S

US $0.01 - 0.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 2N3904 is an NPN general purpose amplifier. The 2N3904 is designed as a general purpose amplifier and switch. The useful dynamic range extends to 100 mA as a switch and to 100 MHz as an amplifier.

Parametrics

2N3904 absolute maximum ratings: (1)Collector-emitter voltage: 40 V; (2)Collector-base voltage: 60 V; (3)Emitter-base voltage: 6.0 V; (4)Collector current - continuous: 200 mA; (5)Operating and storage junction temperature range: -55 to +150 °C.

Features

2N3904 features: (1)V(BR)CEO Collector-Emitter Breakdown Voltage IC = 1.0 mA, IB = 0: 40 V; (2)V(BR)CBO Collector-Base Breakdown Voltage IC = 10 μA, IE = 0: 60 V; (3)V(BR)EBO Emitter-Base Breakdown Voltage IE = 10 μA, IC = 0: 6.0 V; (4)IBL Base Cutoff Current VCE = 30 V, VEB = 3V: 50 nA; (5)ICEX Collector Cutoff Current VCE = 30 V, VEB = 3V: 50 nA.
