Product Summary

The MBM400VS6GA is a 3-pin microprocessor. The ACE809 microprocessor supervisory circuits can be used to monitor the power supplies in microprocessor and digital systems. Application are (1)Embedded systems; (2)Computers; (3)Critical μP Power Supply Monitoring; (4)Battery Powered equipment.




Parametrics

MBM400VS6GA absolute maximum ratings: (1)Supply Voltage VCC: 5.5 V; (2)Output Voltage RESET: -0.3 to (Vcc+0.3)V; (3)Input Current: 20 mA; (4)Output Current IOUT: 20 mA; (5)Thermal resistance junction to ambient SOT-23-3 θJA: 230 ℃/W; (6)Operating junction temperature range TJ: 0 to 125 ℃; (7)Storage temperature range TSTG: -60 to 150°C .

Features

MBM400VS6GA features: (1)Precision Vcc Monitor for 3.0V,3.3V and 5.0V Supplies; (2)140ms Guaranteed Minimum RESET Output Duration; (3)RESET Output Guaranteed to Vcc=1.0V; (4)Low 25μA Supply Current.; (5)Vcc Transient Immunity.; (6)No External Components.

Diagrams

MBM400VS6GA pin connection
