Product Summary
The IGP10N60T is a Low Loss IGBT in TrenchStop and Fieldstop technology. It is suitable for Variable Speed Drive for washing machines and air conditioners; induction cooking; Uninterrupted Power Supply.
Parametrics
IGP10N60T absolute maximum ratings: (1)Collector-emitter voltage VCE: 600 V; (2)DC collector current, limited by Tjmax, IC: 20A at TC = 25°C; 10A at TC = 100°C; (4)Pulsed collector current, tp limited by Tjmax, ICpuls: 30 A; (5)Turn off safe operating area VCE ≤ 600V, Tj ≤ 175°C: 30 A; (6)Gate-emitter voltage, VGE: ±20 V; (7)Short circuit withstand time, VGE = 15V, VCC ≤ 400V, Tj≤ 150°C , tSC: 5 μs; (8)Power dissipation TC = 25°C, Ptot: 110 W; (9)Operating junction temperature, Tj: -40 to +175°C; (10)Storage temperature, Tstg: -55 to +175 °C; (11)Soldering temperature, 1.6mm (0.063 in.) from case for 10s: 260 °C.
Features
IGP10N60T features: (1)Very low VCE(sat) 1.5 V (typ.); (2)Maximum Junction Temperature 175 °C; (3)Short circuit withstand time – 5us; (4)Designed for: Variable Speed Drive for washing machines and air conditioners; induction cooking; Uninterrupted Power Supply; (5)TrenchStop and Fieldstop technology for 600 V applications offers: very tight parameter distribution; high ruggedness, temperature stable behaviour; (6)NPT technology offers easy parallel switching capability due to positive temperature coefficient in VCE(sat); (7)Low EMI; (8)Low Gate Charge; (9)Qualified according to JEDEC1 for target applications; (10)Pb-free lead plating; RoHS compliant; (11)Complete product spectrum and PSpice Models.
Diagrams
