1MBI200NA-120

1MBI200NA-120, IGBT module, 1200 V, 200 A, 1500 W, DIP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $70.00~80.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 10 :	80.00 / Piece
11 ~ 100 :	75.00 / Piece
101 ~ 1000 :	70.00 / Piece

PartNumber:: 1MBI200NA-120

Brand:: FUJI electric - FUJI | D/C: 14+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-27

From Other Seller

Part Number:1MBI200NA-120
US $70.00 - 80.00
Quantity:

piece

Product Summary

The 1MBI200NA-120 is an IGBT module. Applications are (1)High power switching; (2)A.C. motor controls; (3)D.C. motor controls; (4)Uninterruptible power supply.

Parametrics

1MBI200NA-120 absolute maximum ratings: (1)Collector-Emitter Voltage VCES: 1200 V; (2)Gate -Emitter Voltage VGES: ± 20 V; (3)Continuous Collector IC: 200 A; 1ms IC PULSE: 400 A; -IC: 200 A; 1ms -IC PULSE: 400 A; (4)Max. Power Dissipation PC: 1500 W; (5)Operating Temperature Tj: +150 °C; (6)Storage Temperature Tstg: -40 ~ +125 °C; (7)Isolation Voltage A.C. 1min Vis: 2500 V; (8)Screw Torque Mounting 1: 3.5 Nm; Terminals 2: 4.5 Nm; Terminals 3: 1.7 Nm.

Features

1MBI200NA-120 features: (1)Square RBSOA; (2)Low saturation voltage; (3)Less total power dissipation; (4)Improved FWD characteristic; (5)Minimized internal stray inductance; (6)Overcurrent limiting function (4~5 times rated current).
