HFKP

HFKP, automotive relay, 20 mV to 250 mV, 30 A, Hongfa Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.00 / Piece
100 ~ 1000 :	0.80 / Piece
1000 ~ 100000 :	0.50 / Piece

PartNumber:: HFKP

Brand:: Hongfa Technology - HONGFA | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-23

From Other Seller

Part Number:HFKP
US $0.50 - 1.00
Quantity:

piece

Product Summary

The HFKP is an automotive relay. The applications of the HFKP include Central door lock, Anti-theft lock, Power doors & windows, Turning lamp, dangerous signal & scram lamp control, Seat adjustment, Audio system, Air-conditioning, Fuel pump control, Low temperature control, Rear window defoggers, Sunroof motor control, Starter solenoid switches.

Parametrics

HFKP absolute maximum ratings: (1)Contact arrangement: 1 A, 1 C; (2)Voltage drop: Typ.: 20 mV to 250 mV; (3)Max. continuous current: 30 A; (4)Max. switching current: 100 A; (5)Max. switching voltage: 75 VDC; (6)Min. contact load: 1 A 6 VDC; (7)Electrical endurance: See “Contact data”; (8)Mechanical endurance: 1 × 10 7OPS; (9)Initial insulation resistance: 500 MΩ; (10)Dielectric strength: 500 VAC; (11)Operate time: TYp.: 5 ms; (12)Release time: TYp.: 3 ms.

Features

HFKP features: (1)45 A switching capability; (2)PCB terminal; (3)Two pin layout choices; (4)1 Form A & 1 Form C contact arrangement; (5)Unenclosed and plastic sealed types available; (6)RoHS & ELV compliant.
