Product Summary
The HF158F is a half controlled single phase rectifier bridge. Applications are (1)Supply for DC power equipment; (2)DC motor contro.
Parametrics
HF158F absolute maximum ratings: (1)dAVM module: 21 A; (2)VR = 0 V t = 8.3 ms (60 Hz), sine: 210 A; (3)VR = 0 V t = 8.3 ms (60 Hz), sine: 190 A; (4)VR = 0 V t = 8.3 ms (60 Hz), sine: 180 A2 s; (5)VR = 0 V t = 8.3 ms (60 Hz), sine: 145 A2; (6)(dv/dt)cr TVJ = TVJM; VDR = 2/3 VDRM 1000 V/s RGK = ; method 1 (linear voltage rise): 1000 V/μS.
Features
HF158F features: (1)Package with DCB ceramic base plate; (2)Isolation voltage 3600 V~; (3); (4)Planar passivated chips; (5); (6)1/4" fast-on terminals; (7); (8)UL registered E 7287.
Diagrams
