The TPCA8019-H is a High Speed and High Efficiency DC-DC Converter.
Parametrics
TPCA8019-H absolute maximum ratings: (1)Drain-source voltage, VDSS: 200 V; (2)Drain-gate voltage (RGS = 20 kΩ), VDGR: 200 V; (3)Gate-source voltage VGSS: ±20 V; (4)Drain current, DC (Note 1) ID: 27A; Pulsed (Note 1) IDP: 5.5A; (5)Drain power dissipation (Tc=25℃), PD: 11 W; (6)Drain power dissipation (t = 10 s), PD: 15W; (7)Drain power dissipation (t = 10 s), PD: 2.8 W; (8)Single pulse avalanche energy, EAS: 19 mJ; (9)Avalanche current IAR: 5.5 A; (10)Repetitive avalanche energy(Tc=25℃), EAR: 1.5 mJ; (11)Channel temperature, Tch: 150℃; (12)Storage temperature range, Tstg: -55 to 150℃.
Features
TPCA8019-H features: (1)Small footprint due to small and thin package; (2)High speed switching; (3)Small gate charge: Qg = 10nC (typ.); (4)Low drain-source ON resistance: RDS (ON) = 380mΩ (typ.); (5)High forward transfer admittance: |Yfs| = S (typ.); (6)Low leakage current: IDSS = 100 μA (max) (VDS = 100 V) Enhancement mode: Vth = 2 to 4V (V DS = 10 V, ID = 1 mA).
