Product Summary

The TC4426EOA71 is a Dual High-Speed Power MOSFET Drivers. The TC4426EOA71 is highly latch-up resistant under any conditions within their power and voltage ratings. The TC4426EOA71 is not subject to damage when up to 5V of noise spiking (of either polarity) occurs on the ground pin. They can accept, without damage or logic upset, up to 500 mA of reverse current (of either polarity) being forced back into their outputs. All terminals are fully protected against Electrostatic Discharge (ESD) up to 4 kV.

Parametrics

TC4426EOA71 absolute maximum ratings : (1)Supply Voltage:+22V; (2)Input Voltage, IN A or IN B: (VDD + 0.3V) to (GND – 5V); (3)Package Power Dissipation (TA ≤ 70℃) DFN: Note 3; (4)MSOP: 340 mW; (5)PDIP: 730 mW; (6)SOIC: 470 mW; (7)Storage Temperature Range: -65℃ to +150℃; (8)Maximum Junction Temperature: +150℃.

Features

TC4426EOA71 features: (1)High Peak Output Current -1.5A; (2)Wide Input Supply Voltage Operating Range: - 4.5V to 18V; (3)High Capacitive Load Drive Capability -1000 pF in 25 ns (typ.); (4)Short Delay Times -40 ns (typ.); (5)Matched Rise and Fall Times; (6)Low Output Impedance -7Ω; (7)Latch-Up Protected: Will Withstand 0.5A Reverse Current; (8)Input Will Withstand Negative Inputs Up to 5V; (9)ESD Protected ?4 kV; (10)Pin-compatible with the TC426/TC427/TC428; (11)Space-saving 8-Pin MSOP and 8-Pin 6x5 DFN Packages.
