Product Summary
The M1MA142KT1 is a single silicon switching diode. It is designed for use in ultra high speed switching applications. The M1MA142KT1 is housed in the SC--70 package which is designed for low power surface mount applications.
Parametrics
M1MA142KT1 absolute maximum ratings: (1)Reverse Voltage VR: 80Vdc; (2)Peak Reverse Voltage VRM: 80Vdc; (3)Forward Current IF: 100 mAdc; (4)Peak Forward Current IFM: 225 mAdc; (5)Peak Forward Surge Current IFSM: 500 mAdc.
Features
M1MA142KT1 features: (1)Fast trr, < 3.0 ns; (2)Low CD, < 2.0 pF; (3)The Device is Pb--Free, Halogen Free/BFR Free and is RoHS Compliant.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() M1MA142KT1 |
![]() ON Semiconductor |
![]() Diodes (General Purpose, Power, Switching) 80V 100mA |
![]() Data Sheet |
![]() Negotiable |
|
||||||||||||
![]() |
![]() M1MA142KT1G |
![]() ON Semiconductor |
![]() Diodes (General Purpose, Power, Switching) 80V 100mA |
![]() Data Sheet |
![]()
|
|
