Product Summary

The STM8S105K4T6C is an access line 8-bit microcontroller which offers from 16 to 32 Kbytes Flash program memory, plus integrated true data EEPROM. It is referred to as medium-density devices in the STM8S microcontroller family reference manual (RM0016).

Parametrics

STM8S105K4T6C absolute maximum ratings: (1)Supply voltage: -0.3 to 6.5V; (2)Input voltage on true open drain pins: VSS-0.3 to 6.5V; (3)Input voltage on any other pin: VSS-0.3 to VDD+0.3V; (4)Variations between different power pins: 50mV; (5)Variations between all the different ground :50mV.

Features

STM8S105K4T6C features: (1)16 MHz advanced STM8 core with Harvard architecture and 3-stage pipeline; (2)Extended instruction set; (3)Medium-density Flash/EEPROM; (4)RAM: Up to 2 Kbytes; (5)Clock, reset and supply management; (6)Communications interfaces; (7)Analog-to-digital converter (ADC); (8)Up to 38 I/Os on a 48-pin package including 16 high sink outputs; (9)Highly robust I/O design, immune against current injection.

Diagrams

Block diagram Block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
STM8S105K4T6C
STM8S105K4T6C

STMicroelectronics

8-bit Microcontrollers (MCU) Access Line 16 MHz 8-bit MCU 32 Kbyt

Data Sheet

0-870: $0.68
870-1000: $0.57
1000-2000: $0.53
2000-5000: $0.51
STM8S105K4T6CTR
STM8S105K4T6CTR

STMicroelectronics

8-bit Microcontrollers (MCU) Access line MCU 32Kbyt 16 MHz

Data Sheet

0-1660: $0.57
1660-2000: $0.53
2000-2400: $0.53
