MP2249DQT-LF-Z

Low-Voltage Synchronous Step-Down Converter, 1MHz, 6V, 3A, QFN

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.00 / Piece
100 ~ 1000 :	0.80 / Piece
1000 ~ 100000 :	0.50 / Piece

PartNumber:: MP2249DQT-LF-Z

Brand:: Monolithic Power Systems - MPS | Pack: QFN | D/C: 13+

Availability:: Supply Ability: 1000000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-14

From Other Seller

Part Number:MP2249DQT-LF-Z
US $0.50 - 1.00
Quantity:

piece

Product Summary

The MP2249DQT-LF-Z is a 1MHz constant frequency, current mode, PWM step-down converter. The device integrates a main switch and a synchronous rectifier for high efficiency and eliminates the need for an external Schottky diode. It is ideal for powering portable equipment that runs from a single cell Lithium-Ion (Li+) battery. The MP2249DQT-LF-Z can supply 3A of load current from a 2.5V to 6V input voltage. It can run at 100% duty cycle for low dropout applications. The MP2249DQT-LF-Z provides internal soft-start control to reduce rush current and output discharge function to control discharging of the output capacitor. The MP2249DQT-LF-Z is available in small 3mmx3mm TQFN10 or SOIC8E package.

Parametrics

MP2249DQT-LF-Z absolute maximum ratings: (1)Vin (Min)(V): 2.5 V; (2)Vin (Max)(V): 6 V; (3)lout (Max)(A): 3 A; (4)Isw Valley Limit (Typ)(A): 4.5 A; (5)Iq (Typ)(mA): 0.48 mA; (6)Vfb (V): 0.6 V.

Features

MP2249DQT-LF-Z features: (1)High Efficiency: Up to 90%; (2)Power-Save Mode at Light Load; (3)1MHz Constant Switching Frequency; (4)Up to 4.5A Peak Current; (5)2.5V to 6V Input Voltage Range; (6)Output Adjustable from 0.6V to VIN; (7)100% Duty Cycle in Dropout; (8)Output Discharge Function; (9)Internal Soft-Start Control; (10)Power Good Indicator; (11)Short Circuit Protection; (12)Thermal Fault Protection; (13)Available in a 3x3mm TQFN10 or SOIC8E Package.
