MIC29302WT

MIC29302WT, TO, high-current low-dropout regulator, –20V to +60V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: MIC29302WT

Brand:: Micrel Semiconductor - Micrel | Pack: TO | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-26

From Other Seller

Part Number:MIC29302WT
US $0.30 - 0.50
Quantity:

piece

Product Summary

The MIC29302WT is a high current, high accuracy, low-dropout voltage regulator. Using Micrel proprietary Super βeta PNP process with a PNP pass element, these regulators feature 350mV to 425mV (full load) typical dropout voltages and very low ground current. Designed for high current loads, these devices also find applications in lower current, extremely low dropout-critical systems, where their tiny dropout voltage and ground current values are important attributes. The MIC29302WT is fully protected against overcurrent faults, reversed input polarity, reversed lead insertion, overtemperature operation, and positive and negative transient voltage spikes. The MIC29302WTcan be applied in battery powered equipment, high-efficiency green computer systems automotive electronics, high-efficiency linear lower supplies, and high-efficiency lost-regulator for switching supply.

Parametrics

MIC29302WT absolute maximum ratings: (1)Input Supply Voltage (VIN): –20V to +60V ; (2)Enable Input Voltage (VEN): –0.3V to VIN; (3)Lead Temperature (soldering, 5sec.): 260°C; (4)Power Dissipation: Internally Limited ; (5)Storage Temperature Range: –65°C to +150°C.

Features

MIC29302WT features: (1)High current capability; (2)Low-dropout voltage; (3)Low ground current; (4)Accurate 1% guaranteed tolerance; (5)Extremely fast transient response; (6)Reverse-battery and “Load Dump” protection ; (7)Zero-current shutdown mode (5-pin versions); (8)Error flag signals output out-of-regulation (5-pin versions); (9)Also characterized for smaller loads with industryleading performance specifications; (10)Fixed voltage and adjustable versions.
