MAX232ESE+T

MAX232ESE+T, line driver/receiver, 6V, 696mW, 10uA, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	3.00 / Piece
501 ~ 1000 :	2.00 / Piece
1001 ~ 3000 :	1.00 / Piece

PartNumber:: MAX232ESE+T

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-01

From Other Seller

Part Number:MAX232ESE+T
US $1.00 - 3.00
Quantity:

piece

Product Summary

The MAX232ESE+T is a line driver/receiver which is intended for all EIA/TIA-232E and V.28/V.24 communications interfaces, particularly applications where ±12V is not available. Its temperature range would be from -40°C to +85°C and its pin-package would be 16 narrow SO. Applications of the MAX232ESE+T (1) Portable computers. (2) Low power modems. (3) Interface translation. (4) Battery powered RS-232 systems. (5) Multidrop RS-232 networks. That are all the main applications.

Parametrics

MAX232ESE+T absolute maximum ratings: (1) supply voltage (Vcc): -0.3V to +6V. (2) V+: (Vcc - 0.3V) to +14V. (3) V-: +0.3V to +14V. (4) input voltages: -0.3V to (Vcc - 0.3V). (5) output voltages: ±15V for Tout and: from -0.3V to (VCC + 0.3V) for Rout. (6) driver / receiver output short circuited to GND: continuous. (7) continuous power dissipation (Ta = +70°C): 696mW. (8) operating temperature range: -40°C to +85°C. (9) storage temperature range: from -65°C to +160°C. (10) lead temperature (soldering, 10s): +300°C.

Features

MAX232ESE+T features:(1) Its output voltage swing would be min ±5V and max ±8V. (2) Its input logic threshold low would be typ 1.4V and max 0.8V. (3) Its input logic threshold high would be min 2V and typ 1.4V. (4) Its logic pullup / input current would be typ 5uA and max 40uA. (5) Its output leakage current would be typ ±0.01uA and max ±10uA. (6) Its data rate would be typ 200kbps and max 116kbps.
