MAX13485EESA

MAX13485EESA, Half-Duplex RS-485/RS-422 Transceiver, SOIC, 471mW, 6V, Maxim Integrated Products

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: MAX13485EESA

Brand:: Maxim Integrated Products - Maxim | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-26

From Other Seller

Part Number:MAX13485EESA
US $0.30 - 0.50
Quantity:

piece

Product Summary

The MAX13485EESA is a Half-Duplex RS-485/RS-422 Transceiver. The MAX13485EESA +5V, half-duplex, ±15kV ESD-protected RS-485 transceivers feature one driver and one receiver. The MAX13485EESA includes fail-safe circuitry, guaranteeing a logic-high receiver output when receiver inputs are open or shorted. The receiver outputs logic high if all transmitters on a terminated bus are disabled (high impedance). The MAX13485EESA include a hot-swap capability to eliminate false transitions on the bus during power-up or live-insertion. The MAX13485EESA features reduced slew-rate drivers that minimize EMI and reduce reflections caused by improperly terminated cables, allowing error-free transmission up to 500kbps. The MAX13485EESA driver slew rate is not limited, allowing transmit speeds up to 16Mbps. The applications of the MAX13485EESA include Utility Meters, Industrial Controls, Industrial Motor Drives and Automated HVAC Systems.

Parametrics

MAX13485EESA absolute maximum ratings: (1)VCC: +6V; (2)DE, RE, DI: -0.3V to +6V; (3)A, B: -8V to 13V; (4)Short-Circuit Duration (RO, A, B) to GND: Continuous; (5)Continuous Power Dissipation: 471mW; (6)Operating Temperature Range: -40℃ to +85℃; (7)Junction Temperature:+150℃; (8)Storage Temperature Range: -65℃ to +150℃; (9)Lead Temperature (soldering, 10s): +300℃.

Features

MAX13485EESA features: (1)+5V Operation; (2)True Fail-Safe Receiver While Maintaining EIA/TIA-485 Compatibility; (3)Hot-Swappable for Telecom Applications; (4)Enhanced Slew-Rate Limiting Facilitates Error- Free Data Transmission (MAX13485E); (5)High-Speed Version (MAX13488E) Allows form Transmission Speeds Up to 16Mbps; (6)Extended ESD Protection for RS-485/RS-422 I/O Pins ±15kV Using Human Body Model; (7)1/4 Unit Load, Allowing Up to 128 Transceivers on the Bus; (8)Available in Space-Saving 8-Pin μDFN or Industry Standard 8-Pin SO Packages.
