DS18B20+T

DS18B20+T, 1-Wire Digital Thermometer, 6.0 V, 750 ms, 12-bit, TO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.60~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	1.00 / Piece
1001 ~ 10000 :	0.80 / Piece
10001 ~ 100000 :	0.60 / Piece

PartNumber:: DS18B20+T

Brand:: Maxim Integrated Products - Maxim | Pack: TO | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-03

From Other Seller

Part Number:DS18B20+T
US $0.60 - 1.00
Quantity:

piece

Product Summary

The DS18B20+T is a 1-Wire Digital Thermometer. It provides 9-bit to 12-bit Celsius temperature measurements and has an alarm function with nonvolatile user-programmable upper and lower trigger points. The DS18B20+T communicates over a 1-Wire bus that by definition requires only one data line (and ground) for communication with a central microprocessor. The applications of the DS18B20+T are Thermostatic Controls, Industrial Systems, Consumer Products, Thermometers, or Any Thermally Sensitive System.

Parametrics

DS18B20+T absolute maximum ratings: (1)Voltage Range on Any Pin Relative to Ground:-0.5V to +6.0V; (2)Operating Temperature Range:-55℃ to +125℃; (3)Storage Temperature Range:-55℃ to +125℃.

Features

DS18B20+T features: (1)Unique 1-Wire Interface Requires Only One Port Pin for Communication ; (2)Each Device has a Unique 64-Bit Serial Code Stored in an On-Board ROM ; (3)Multidrop Capability Simplifies Distributed Temperature-Sensing Applications ; (4)Requires No External Components ; (5)Can Be Powered from Data Line; Power Supply Range is 3.0V to 5.5V ; (6)Measures Temperatures from -55℃ to +125℃; (7)±0.5℃ Accuracy from -10℃ to +85℃; (8)Thermometer Resolution is User Selectable from 9 to 12 Bits ; (9)Converts Temperature to 12-Bit Digital Word in 750ms (Max).
