ATMEGA2560-16AU

ATMEGA2560-16AU, low-power, CMOS 8-bit microcontroller, TQFP, 200mA, 40mA, ATMEL Corporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $4.50~6.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	6.50 / Piece
101 ~ 1000 :	5.50 / Piece
1001 ~ 10000 :	4.50 / Piece

PartNumber:: ATMEGA2560-16AU

Brand:: ATMEL Corporation - ATMEL | Pack: TQFP | D/C: 14+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-11

From Other Seller

Part Number:ATMEGA2560-16AU
US $4.50 - 6.50
Quantity:

piece

Product Summary

The ATMEGA2560-16AU is a low-power CMOS 8-bit microcontroller based on the AVR enhanced RISC architecture. By executing powerful instructions in a single clock cycle, the ATMEGA2560-16AU achieves throughputs approaching 1 MIPS per MHz allowing the system designer to optimize power consumption versus processing speed.

Parametrics

ATMEGA2560-16AU absolute maximum ratings: (1)Operating Temperature: -55 to +125℃; (2)Storage Temperature: -65 to +150℃; (3)Voltage on any Pin except RESET with respect to Ground: -0.5V to VCC+0.5V; (4)Voltage on RESET with respect to Ground: -0.5V to +13.0V; (5)Maximum Operating Voltage: 6.0V; (6)DC Current per I/O Pin: 40.0 mA; (7)DC Current VCC and GND Pins: 200.0 mA.

Features

ATMEGA2560-16AU features: (1)High Performance, Low Power AVR?8-Bit Microcontroller; (2)Advanced RISC Architecture; (3)Non-volatile Program and Data Memories; (4)JTAG (IEEE std. 1149.1 compliant) Interface; (5)Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode; (6)Four 16-bit Timer/Counter with Separate Prescaler, Compare- and Capture Mode; (7)Real Time Counter with Separate Oscillator; (8)Four 8-bit PWM Channels; (9)Six/Twelve PWM Channels with Programmable Resolution from 2 to 16 Bits (ATmega1281/2561, ATmega640/1280/2560); (10)Output Compare Modulator; (11)8/16-channel, 10-bit ADC (ATmega1281/2561, ATmega640/1280/2560); (12)Two/Four Programmable Serial USART (ATmega1281/2561,ATmega640/1280/2560); (13)Master/Slave SPI Serial Interface; (14)Byte Oriented 2-wire Serial Interface; (15)Programmable Watchdog Timer with Separate On-chip Oscillator; (16)On-chip Analog Comparator; (17)Interrupt and Wake-up on Pin Change.
