PBSS5140T

PBSS5140T, transistor, 300 mW, 40 V, 2 A, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: PBSS5140T

Brand:: NXP Semiconductors - nxp | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-18

From Other Seller

Part Number:PBSS5140T
US $0.30 - 0.50
Quantity:

piece

Product Summary

The PBSS5140T is a vcesat pnp transistor. Applications are: (1)General purpose switching and muting; (2)LCD back lighting; (3)Supply line switching circuits; (4)Battery driven equipment (mobile phones, video cameras and hand-held devices).

Parametrics

PBSS5140T absolute maximum ratings: (1)VCBO collector-base voltage open emitter: -40 V; (2)VCEO collector-emitter voltage open base: -40 V; (3)VEBO emitter-base voltage open collector: -5 V; (4)IC collector current (DC): -1 A; (5)ICM peak collector current: -2 A; (6)IBM peak base current: -1 A; (7)Ptot total power dissipation Tamb ≤ 25 °C; note 1 - 300 mW; Tamb ≤ 25 °C; note 2: 450 mW; (8)Tstg storage temperature: -65 +150 °C; (9)Tj junction temperature: 150 °C; (10)Tamb operating ambient temperature: -65 +150 °C.

Features

PBSS5140T features: (1)Low collector-emitter saturation voltage; (2)High current capabilities; (3)Improved device reliability due to reduced heat generation.
