Product Summary

The ESAD92-02 is a low loss super high speed rectifier. It can be applied in high speed power switching.

Parametrics

ESAD92-02 absolute maximum ratings: (1)Repetitive peak reverse voltage: 200V; (2)Average output current: 20A; (3)Surge current: 100A; (4)Operating junction temperature: -40 to +150°C; (5)Storage temperature: -40 to +150°C.

Features

ESAD92-02 features: (1)Low VF; (2)Super high speed switching; (3)High reliability by planer design.

Diagrams

ESAD92-02 outline drawing
