Product Summary

The HR 25-7TP-8P (73) is a high-density round type connector. The HR 25-7TP-8P (73) was developed using Hirose Electric’s long experience with miniaturization technology in answer to the continuing need for the ever greater miniaturization and high-density construction of a wide variety of electronic equipment. The applications of the HR 25-7TP-8P (73) include CCD cameras, measuring instruments, wide variety of sensors, mobile radio, medical equipment, etc.

Features

HR 25-7TP-8P (73) features: (1)The HR 25-7TP-8P (73) is the world’s smallest high--density connector; (2)The structure is such that the pins will not become misshapen even if the male pins are inserted incorrectly; (3)These connectors prevent water from entering the interior of the set; (4)Contacts are gold plated as a standard to maintain contact stability; (5)The number of contacts is available in 4, 6, 8, 12, 16, or 20 contacts allowing these connectors to be used over a wide range of applications; (6)Available in a variety of types.

Diagrams

HR 25-7TP-8P (73) block diagram
