Product Summary

<p style="line-height:180%;" align="left">
1. Brand new and high quality. <br />
2. Low-noise receive gain. <br />
3. Signal activity LED indicates <br />
4. High Gain, High Value, High Performance. <br />
5. Maximum output power of 8000mW by the Booster. <br />
6. Plug-and-play, Easy installation, no driver needed. <br />
7. Ideal for increase the 2400-2500Mhz frequency devices. <br />
8. Increase the effective range and coverage area of your Wi-Fi network. <br />
9. Simply attach the booster in between the standard antenna on a wireless router or wireless access point and watch your range grow. <br />
10. The amplified wireless signal may even penetrate complex environments with many walls and obstacles. <br />
11. Ideal for use with 2.4GHz Wireless LANs, Support 802.11b, 802.11g, 802.11n (2.4Ghz mode only). <br />
12. NOTE: The item need connect with the Access Point Router together ,then it can work and the Access Point Router is NOT included.
</p>

Features

. Operation Range: 2400-2500 MHz. <br />
2. Operation Mode: Bi-directional, half-duplex, Auto-Switching via carrier sensing. <br />
3. Frequency Response: ± 1dB over operation range. <br />
4. Input Power: 3dBm (Min.)-20dBm (Max.). <br />
5. Input Power 5 ~ 20 dBm. <br />
6. Optimal Input Power 9 ~ 13 dBm. <br />
7. Output Power: 8000mW/39dBm nominal for 802.11b/11Mbps. <br />
8. Connector: SMA Receptacle, 50 ohm. <br />
9. Transmit Gain: 17dBm nominal. <br />
10. Receiver Gain: 11dBm. <br />
11. Receive Noise Figure: 3.0dBm nominal. <br />
12. Operating Temperature: -40 to 70 degree. <br />
13. Operating Humidity: Up to 95% relative humidity. <br />
14. Material: Cast Aluminum. <br />
15. Size:10.3cm x 7.7cm x 2.1cm <br />
16. Weight: 785g
