Product Summary

The GRM31CR71H225KA88L is a rf power ldmos transistor. Designed for mobile two--way radio applications with frequencies from764 to 941 MHz. The high gain, ruggedness and broadband performance of these devices make them ideal for large--signal, common source amplifier applications in mobile radio equipment. Applications are (1)Output Stage 800 MHz Trunking Band Mobile Radio; (2)Output Stage 900 MHz Trunking Band Mobile Radio.

Parametrics

GRM31CR71H225KA88L absolute maximum ratings: (1)Drain--Source Voltage VDSS: -0.5 to +40 Vdc; (2)Gate--Source Voltage VGS: -6.0 to +12 Vdc; (3)Operating Voltage VDD: 17 Vdc; (4)Storage Temperature Range Tstg: -65°C to +150 °C; (5)Case Operating Temperature TC: -40 to +150 °C; (6)Operating Junction Temperature (1,2)TJ: -40°C to +225 °C; (7)Total Device Dissipation @ TC = 25°C Derate above 25°C PD: 317 W .

Features

GRM31CR71H225KA88L features: (1)Characterized for Operation from 764 to 941 MHz; (2)Unmatched Input and Output Allowing Wide Frequency Range Utilization; (3)Integrated ESD Protection; (4)Integrated Stability Enhancements; (5)Wideband ó Full Power Across the Band (764ñ870 MHz); (6)225°C Capable Plastic Package; (7)Exceptional Thermal Performance; (8)High Linearity for: TETRA, SSB, LTE; (9)Cost--effective Over--molded Plastic Packaging; (10)In Tape and Reel. R1 Suffix = 500 Units, 24 mm Tape Width, 13 inch Reel.

Diagrams

GRM31CR71H225KA88L pin connection

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
GRM31CR71H225KA88L
GRM31CR71H225KA88L

Murata

Multilayer Ceramic Capacitors (MLCC) - SMD/SMT 1206 2.2uF 50volts X7R 10%

Data Sheet

0-1: $0.10
1-50: $0.08
50-100: $0.08
100-500: $0.05
