SFH610A-2

optocoupler, 150mW, 70V, DIP4

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.35~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	0.50 / Piece
100 ~ 1000 :	0.40 / Piece
1000 ~ 10000 :	0.35 / Piece

PartNumber:: SFH610A-2

Brand:: Vishay Siliconix - Vishay | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-11

From Other Seller

Part Number:SFH610A-2
US $0.35 - 0.50
Quantity:

piece

Product Summary

The sfh610a-2 is an optocoupler with phototransistor output, high reliability. The sfh610a-2 features a high current transfer ratio, low coupling capacitance and high isolation voltage. The sfh610a-2 is incorporated in a plastic DIP-4 or SMD package.

Parametrics

sfh610a-2 absolute maximum ratings: (1) Reverse voltage VR: 6V; (2) DC Forward current IF:60mA; (3) Surge forward current IFSM: 2.5A; (4) Power dissipation Pdiss: 100mW; (5) Collector-emitter voltage VCE: 70V; (6) Emitter-collector voltage VEC: 7V; (7) Collector current: 50mA, 100mA (t≤1ms) ; (8) Power dissipation Pdiss: 150mW.

Features

sfh610a-2 features: (1) Good CTR Linearity Depending on Forward Current; (2) Isolation Test Voltage, 5300 VRMS; (3) High Collector-Emitter Voltage, VCEO=70V; (4) Low Saturation Voltage; (5) Fast Switching Times; (6) Low CTR Degradation; (7) Low Coupling Capacitance; (8) High Common-Mode Interference Immunity; (9) Lead (Pb)-free component; (10) Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC.
