Product Summary

The TRV4 is a General Purpose / Industrial Relay.

Parametrics

TRV4 absolute maximum ratings: (1)Insulation Resistance: 100MΩMin at 500VDC; (2)Dielectric Strength Between Open Contacts: 500VAC; (3)Between Contacts and coil: 750VAC(for one minute); (4)Operate Time: 10ms; (5)Release Time: 10ms; (6)Temperature Range: -40 ℃ to +85 ℃; (7)Shock Resistance Operating Extremes: 10G; (8)Shock Resistance Damage Limits: 20G; (9)Vibration Resistance: 10 to 40Hz, 1.5mm; (10)Max. switching frequency: Mechanical: 18,000operations/hr, Electrical: 1,800operations/hr; (11)Humidity: 40-85%; (12)Weight: Approx 40g.

Features

TRV4 features: (1)40A continuous rating 85 ℃; (2)1A&1C arrangements; (3)Plug-in or PC board terminals; (4)Optional mounting bracket; (5)Conform to RoHS,ELV directive.

Diagrams

TRV4 block diagram
