HFKW

HFKW, subminiature automotive relay, 500 VAC, 35 A, Hongfa Technology

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	1.00 / Piece
100 ~ 1000 :	0.80 / Piece
1000 ~ 10000 :	0.50 / Piece

PartNumber:: HFKW

Brand:: Hongfa Technology - HONGFA | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-23

From Other Seller

Part Number:HFKW
US $0.50 - 1.00
Quantity:

piece

Product Summary

The HFKW is a subminiature automotive relay.

Parametrics

HFKW absolute maximum ratings: (1)Contact arrangement: 1 A, 1 C; (2)Voltage drop: Typ.: 50 mV to 250 mV; (3)Max. continuous current: 35 A; (4)Max. switching current: 35 A; (5)Max. switching voltage: 16 VDC; (6)Min. contact load: 1 A 6 VDC; (7)Electrical endurance: See “Contact data”; (8)Mechanical endurance: 1 × 10 7OPS; (9)Initial insulation resistance: 100 MΩ; (10)Dielectric strength: 500 VAC.

Features

HFKW features: (1)Tight structure and light weight; (2)High current contact capacity; (3)Improved heat resistance; (4)Reflow soldering version available; (5)RohS & ELV compliant.
