Product Summary

The MI-J20-MY is a Military DC-DC Converter. The MI-J20-MY is designed for military applications utilizing distributed power architectures. Based on Vicor’s 1st Generation family of zero-current/zero-voltage switching, component-level, DC-DC converters, the MI-J20-MY offers state-of-the-art performance in terms of power density, efficiency, noise, ease of use, and reliability.

Parametrics

MI-J20-MY absolute maximum ratings: (1)Gate-in high threshold: 6 V; (2)Gate-in low threshold: 0.65 V; (3)Gate-in low current: 6 mA; (4)Efficiency: 80 to 90 %; (5)Baseplate to sink: 0.14 ℃/W; (6)Baseplate operating temperature: +100 ℃; (7)Storage temperature: +125 ℃.

Features

MI-J20-MY features: (1)Single output: 2 – 48Vdc; (2)Up to 23W/in3; (3)MIL-STD-810 environments; (4)Up to 90% efficiency; (5)Remote sense; (6)Current limit; (7)ZVS/ZCS power architecture; (8)Low noise FM control.

Diagrams

MI-J20-MY dimension
