Product Summary

The UNI1403 is a high-speed transient surge protector. The UNI1403 provides the ultimate protection from high-energy, fast-rising transients such as Nuclear EMP. The UNI1403 is constructed using a proprietary semiconductor junction process that results in nanosecond response times combined with peak current ratings in excess of 20kA. A unique benefit of this technology is that the breakdown voltage is virtually independent of the rise time of the transient. In addition, the low capacitance of the UNI1403 allows for direct placement on high-frequency lines and antenna feeds without excessive loading. The applications of the UNI1403 include Antenna feedlines, Test equipment, Video displays, Medical electronics, Instrumentation circuits.

Parametrics

UNI1403 absolute maximum ratings: (1)DC Breakdown: 100V/s; (2)Impulse Breakdown: 5kV/μs; (3)Insulation Resistance: 100V; (4)Capacitance: 1MHz ; (5)Surge Life: 3kA (PW=15μs).

Features

UNI1403 features: (1)Fast impulse breakdown (≤120% of typical DC breakdown to 200kV/μs); (2)Tight DC breakdown voltage tolerance (±10%); (3)Non-radioactive; (4)Low capacitance.

Diagrams

UNI1403 block diagram
