LM9076QBMA-3.3

LM9076QBMA-3.3, voltage regulator, 55 V, 2 kV, 100 μA, 200 mV, 150 mA, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: LM9076QBMA-3.3

Brand:: Texas Instruments - TI | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-18

From Other Seller

Part Number:LM9076QBMA-3.3
US $0.30 - 0.50
Quantity:

piece

Product Summary

The LM9076QBMA-3.3 is a ±3%, 150 mA logic controlled voltage regulator. The LM9076QBMA-3.3 features an active low delayed reset output flag which can be used to reset a microprocessor system at turn-ON and in the event that the regulator output voltage falls below a minimum value. An external capacitor programs a delay time interval before the reset output pin can return high.

Parametrics

LM9076QBMA-3.3 absolute maximum ratings: (1)VIN(DC): -15 V to +55 V; (2)VIN(+Transient)t< 10 ms, Duty Cycle <1%: +70 V; (3)VIN(-Transient)t< 1 ms, Duty Cycle <1%: -50 V; (4)SHUTDOWN Pin: -15 V to +52 V; (5)RESET Pin: -0.3 V to 20 V; (6)CDELAY Pin: -0.3 V to VOUT +0.3 V; (7)Storage Temperature: -65 °C to +150 °C; (8)Junction Temperature (TJ ): +175 °C; (9)ESD, HBM, per AEC - Q100 - 002: +/-2 kV; (10)ESD, MM, per AEC - Q100 - 003: +/-250 V.

Features

LM9076QBMA-3.3 features: (1)AEC-Q100 Grade1 qualified (-40°C to +125 °C); (2)Available with 5.0 V or 3.3 V output voltage; (3)Ultra Low Ground Pin Current, 25 μA typical for 100 μA load; (4)VOUT initial accuracy of ±1.5%; (5)VOUT accurate to ±3% over Load and Temperature Conditions; (6)Low Dropout Voltage, 200 mV typical with 150 mA load; (7)Low Off State Ground Pin current for LM9076QBMA-3.3; (8)Delayed RESET output pin for low VOUT detection; (9)+70 V/-50 V Voltage Transients; (10)Operational VIN up to +40 V.
