ICL7660CBA

ICL7660CBA, monolithic CMOS power supply circuits, 10.5V, 20μA, SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: ICL7660CBA

Brand:: Intersil Corporation - Intersil | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-18

From Other Seller

Part Number:ICL7660CBA
US $0.30 - 0.50
Quantity:

piece

Product Summary

The ICL7660CBA is a monolithic CMOS power supply circuits which offer unique performance advantages over previously available devices. The ICL7660CBA performs supply voltage conversion from positive to negative for an input range of 1.5V to 10V, resulting in complementary output voltages of -1.5V to -10V. The applications of the ICL7660CBA are On Board Negative Supply for Dynamic RAMs, Localized μProcessor (8080 Type) Negative Supplies, Inexpensive Negative Supplies, Data Acquisition Systems.

Parametrics

ICL7660CBA absolute maximum ratings: (1)Supply Voltage: +10.5V; (2)LV and OSC Input Voltage: -0.3V to (V+ +0.3V) for V+ < 5.5V; (Note 2) : (V+ -5.5V) to (V+ +0.3V) for V+ > 5.5V; (3)Current into LV (Note 2): 20μA for V+ > 3.5V; (4)Output Short Duration (VSUPPLY ≤ 5.5V): Continuous.

Features

ICL7660CBA features: (1)Simple Conversion of +5V Logic Supply to ±5V Supplies; (2)Simple Voltage Multiplication (VOUT = (-) nVIN); (3)Typical Open Circuit Voltage Conversion Efficiency: 99.9%; (4)Typical Power Efficiency: 98%; (5)Wide Operating Voltage Range: 1.5V to 10.0V; (6)ICL7660A 100% Tested at 3V; (7)Easy to Use - Requires Only 2 External Non-Critical Passive Components; (8)No External Diode Over Full Temp. and Voltage Range; (9)Pb-Free Plus Anneal Available (RoHS Compliant).
