XC6201P502MR

positive voltage regulator, low power consumption, 0.40V, 200mA, SOT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: XC6201P502MR

Brand:: Torex Semiconductor - TOREX | Pack: SOT | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-24

From Other Seller

Part Number:XC6201P502MR
US $0.30 - 0.50
Quantity:

piece

Product Summary

The XC6201P502MR is a highly precise, low power consumption, positive voltage regulator manufactured using CMOS and laser trimming technologies. The XC6201P502MR provides large currents with a significantly small dropout voltage. The XC6201P502MR consists of a current limiter circuit, a driver transistor, a precision reference voltage and an error amplifier. Output voltage is selectable in 0.1V steps between 1.3V ~ 6.0V. SOT-25, SOT-89, USP-6B and TO-92 packages are available. Applications include Mobile Phones, Cordless phones, wireless communication equipment, Cameras, video recorders, Portable games, Portable AV equipment, Reference voltage and Battery powered equipment.

Parametrics

XC6201P502MR absolute maximum ratings: (1)Input Voltage: 12.0 V ; (2)Output Current: 500 mA ; (3)Output Voltage: VSS-0.3～VIN+0.3 V; (4)Operating Temperature Range: -40～+85℃; (5)Storage Temperature Range: -55～+125℃.

Features

XC6201P502MR features: (1)Maximum Output Current: 250mA (TYP.) ; (2)Dropout Voltage: 0.16V @ 100mA; 0.40V @ 200mA ; (3)Maximum Operating Voltage: 10V ; (4)Output Voltage Range: 1.3V ~ 6.0V (0.1V increments); (5)Fixed Voltage Accuracy: ±1% (VOUT(T)>2.0V) ±2% ; (6)Low Power Consumption: 2.0μA (TYP.) ; (7)Operational Temperature Range: -40℃ ~ 85℃; (8)Packages: SOT-25, SOT-89, TO-92, USP-6B ; (9)Environmentally Friendly: EU RoHS Compliant, Pb Free ; (10)Tantalum or Ceramic Capacitor compatible
