TPS72501KTTT

TPS72501KTTT, low-dropout (LDO) linear regulator, 1.22 V, 1- μA, 2 kV, TO

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1000 ~ 10000 :	0.40 / Piece
10000 ~ 100000 :	0.30 / Piece

PartNumber:: TPS72501KTTT

Brand:: Texas Instruments - TI | Pack: TO | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-13

From Other Seller

Part Number:TPS72501KTTT
US $0.30 - 0.50
Quantity:

piece

Product Summary

The TPS72501KTTT is a 1-A low-dropout (LDO) linear regulator has fixed voltage options available. The TPS72501KTTT is commonly used to power the latest DSPs, FPGAs and microcontrollers. An adjustable option ranging from 1.22 V to 5.5 V is also available. The integrated supervisory circuitry provides an active low RESET signal when the output falls out of regulation. The no capacitor/any capacitor feature allows the custome to tailor output transient performance as needed. The applications of the TPS72501KTTT include PCI Cards, Modem Banks Telecom Boards, DSP, FPGA, and Microprocessor Power Supplies, Portable, Battery-Powered Applications.

Parametrics

TPS72501KTTT absolute maximum ratings: (1)Input voltage, VI: -0.3 to 7 V; (2)Voltage range at EN, FB: -0.3 to VI+ 0.3 V; (3)Voltage on OUT, RESET: 6 V; (4)ESD rating, HBM: 2 kV; (5)Continuous total power dissipation: See Dissipation Ratings Tabl; (6)Operating junction temperature range, Tj: -50 to 150℃; (7)Maximum junction temperature range, Tj: 150℃; (8)Storage temperature, Tstg: -65 to 150℃.

Features

TPS72501KTTT features: (1)1-A Output Current; (2)Available in 1.5-V, 1.6-V, 1.8-V, 2.5-V Fixed-Output and Adjustable Versions (1.2-V to 5.5-V); (3)Input Voltage Down to 1.8 V; (4)Low 170-mV Dropout Voltage at 1 A (TPS72525); (5)Stable With Any Type/Value Output Capacitor; (6)Integrated Supervisor (SVS) With 50-ms RESET Delay Time; (7)Low 210- μ A Ground Current at Full Load (TPS72525); (8)Less than 1- μ A Standby Current ±2% Output Voltage Tolerance Over Line, Load, and Temperature (-40℃ to 125℃) Integrated UVLO; (9)Thermal and Overcurrent Protection; (10)5-Lead SOT223-5 or DDPAK and 8-Pin SOP (TPS72501 only) Surface Mount Package.
