TPS65270PWPR

TPS65270PWPR, dual synchronous buck regulator, 7 V, 2 A, TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1000 ~ 10000 :	0.40 / Piece
10000 ~ 100000 :	0.30 / Piece

PartNumber:: TPS65270PWPR

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-14

From Other Seller

Part Number:TPS65270PWPR
US $0.30 - 0.50
Quantity:

piece

Product Summary

The TPS65270PWPR is a monolithic dual synchronous buck regulator with wide operating input voltage that can operate in 5-, 9-, 12- or 15-V bus voltages and battery chemistries. The converters are designed to simplify its application while giving the designer the option to optimize their usage according to the target application. Applications are (1)DTV; (2)DSL Modem; (3)Cable Modem; (4)Set Top Boxe; (5)Car DVD Player; (6)Home Gateway and Access Point Network; (7)Wireless Router.

Parametrics

TPS65270PWPR absolute maximum ratings: (1)Voltage range at VIN1, VIN2, LX1, LX2 : –0.3 V to 18 V; (2)Voltage range at LX1, LX2 (maximum withstand voltage transient < 10 ns): –1 V to 18 V; (3)Voltage at BST1, BST2, referenced to LX1, LX2 pin : –0.3 V to 7 V; (4)Voltage at VCC, EN1, EN2, COMP1, COMP2, LOW_P: –0.3 V to 7 V; (5)Voltage at SS1, SS2, FB1, FB2, ROSC : –0.3 V to 3.6 V; (6)Voltage at AGND, GND : –0.3 V to 0.3 V; (7)TJ Operating virtual junction temperature range: –40°C to 125 °C; (8)TSTG Storage temperature range: –55°C to 150 °C.

Features

TPS65270PWPR features: (1)Wide Input Supply Voltage Range (4.5 V - 18 V); (2)0.8 V, ±1% Accuracy Reference; (3)Up to 2-A (Buck 1)and 3-A (Buck 2)Maximum Continuous Output Loading Current; (4)Low Power Pulse Skipping Mode to Achieve High Light Load Efficiency; (5)Adjustable Switching Frequency 300 kHz - 1.4 MHz Set by External Resistor; (6)Dedicated Enable and Soft-Start for Each Buck; (7)Peak Current-Mode Control with Simple Compensation Circuit; (8)Cycle-by-Cycle Over Current Protection.
