TPS54326RGTR

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1000 ~ 10000 :	0.40 / Piece
10000 ~ 100000 :	0.30 / Piece

PartNumber:: TPS54326RGTR

Brand:: Texas Instruments - TI | Pack: QFN | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-12

From Other Seller

Part Number:TPS54326RGTR
US $0.30 - 0.50
Quantity:

piece

Product Summary

The TPS54326RGTR is a adaptive on-time D-CAP2 mode synchronous buck converter. The TPS54326RGTR enables system designers to complete the suite of various end equipment power bus regulators with a cost effective, low component count, low standby current solution. Applications of the TPS54326RGTR include: Digital TV Power Supply, igh Definition Blu-ray Disc Players, Networking Home Terminal and Digital Set Top Box (STB) .

Parametrics

TPS54326RGTR absolute maximum ratings: (1) Input voltage range, VIN, VCC, EN: -0.3 to 20V, VBST: -0.3 to 26V, VBST (VS SW1, SW2) : -0.3 to 6.5V, VFB, VO, SS, PG: -0.3 to 6.5V, SW1, SW2: -2 to 20V, SW1, SW2 (10ns transient) : -3 to 20V; (2) Output voltage range VREG5: -0.3 to 6.5V, PGND1, PGND2: -0.3 to 0.3V; (3) Voltage from GND to POWERPAD: -0.2 to 2V; (4) Operating junction temperature Tj: -40 to 150°C; (5) Storage temperature Tstg: -55 to 150°C.

Features

TPS54326RGTR features: (1) D-CAP2 Mode Enables Fast Transient response; (2) Low Output Ripple and Allows Ceramic Output Capacitor; (3) Wide Vcc Input Voltage Range: 4.5V to 18V; (4) Wide VIN Input Voltage Range: 2V to 18V; (5) Output Voltage Range: 0.76V to 5.5V; (6) High Initial Bandgap Reference Accuracy; (7) Adjustable Soft Start; (8) 700-kHz Switching Frequency (fsw) ; (9) Cycle By Cycle Over Current Limit; (10) Power Good Output; (11) Auto-Skip Mode.
