TPS2375D

TPS2375D, PoE powered device controller, SOIC, 500V, 50mA, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: TPS2375D

Brand:: Texas Instruments - TI | Pack: SOIC | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-17

From Other Seller

Part Number:TPS2375D
US $0.30 - 0.50
Quantity:

piece

Product Summary

The TPS2375D is a PoE powered device controller. These easy-to-use 8-pin integrated circuits contain all of the features needed to develop an IEEE 802.3af compliant powered device (PD). The TPS2375D is a second generation PDC (PD Controller) featuring 100-V ratings and a true open-drain, power-good function. The TPS2375D has 802.3af compliant UVLO limits, the TPS2375D has legacy UVLO limits, and the TPS2375D has a programmable UVLO with a dedicated input pin. The applications of the TPS2375D include VoIP Phones, WLAN Access Points, Security Cameras, Internet Appliances and POS Terminals.

Parametrics

TPS2375D absolute maximum ratings: (1)Voltage: -0.3 V to 10 V; (2)Current, sinking: 0 to 5 mA; (3)Current, sourcing: 0 to 1 mA; (4)ESD: 500 V; (5)Maximum junction temperature range: Internally limited; (6)Storage temperature range: -65℃ to 150℃; (7)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds - Green Packages: 260℃; (8)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds - Nongreen Packages: 235℃.

Features

TPS2375D features: (1)Fully Supports IEEE 802.3af Specification; (2)Integrated 0.58-Ω, 100-V, Low-Side Switch; (3)15-kV System Level ESD Capable; (4)Supports Use of Low-Cost Silicon Rectifiers; (5)Programmable Inrush Current Control; (6)Fixed 450-mA Current Limit; (7)Fixed and Adjustable UVLO Options; (8)Open-Drain, Power-Good Reporting; (9)Over temperature Protection; (10)Industrial Temperature Range: -40℃ to 85℃; (11)8-Pin SOIC and TSSOP Packages.
