TPCA8036-H

TPCA8036-H, Silicon N-Channel MOS Type transistor, QFN, 30 V, 38 A, 45 W, Toshiba Semiconductor

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	3.00 / Piece
501 ~ 1000 :	2.00 / Piece
1001 ~ 3000 :	1.00 / Piece

PartNumber:: TPCA8036-H

Brand:: Toshiba Semiconductor - Toshiba | Pack: QFN | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-25

From Other Seller

Part Number:TPCA8036-H
US $1.00 - 3.00
Quantity:

piece

Product Summary

The TPCA8036-H is a Silicon N-Channel MOS Type transistor.

Parametrics

TPCA8036-H absolute maximum ratings: (1)Drain-source voltage, VDSS: 30 V; (2)Drain-gate voltage (RGS = 20 kΩ), VDGR: 30 V; (3)Gate-source voltage VGSS: ±20 V; (4)Drain current, DC (Note 1) ID: 38A; Pulsed (Note 1) IDP: 114A; (5)Drain power dissipation (Tc=25℃), PD: 45 W; (6)Drain power dissipation (t = 10 s), PD: 2.8 W; (7)Drain power dissipation (t = 10 s), PD: 1.6 W; (8)Single pulse avalanche energy, EAS: 188 mJ; (9)Avalanche current IAR: 38 A; (10)Repetitive avalanche energy(Tc=25℃), EAR: 0.18 mJ; (11)Channel temperature, Tch: 150℃; (12)Storage temperature range, Tstg: -55 to 150℃.

Features

TPCA8036-H features: (1)Small footprint due to a small and thin package; (2)High-speed switching; (3)Small gate charge: QSW = 13 nC (typ.); (4)Low drain-source ON-resistance: RDS (ON) = 2.8 mΩ (typ.); (5)High forward transfer admittance: |Yfs| = 113 S (typ.); (6)Low leakage current: IDSS = 10 μA (max) (VDS = 30 V); (7)Enhancement mode: Vth = 1.3 to 2.3 V (VDS = 10 V, ID = 0.5 mA).
