TPA2010D1YZFT

TPA2010D1YZFT, mono filter-free class-D audio power amplifier, 2.5-W, 6 V, 55 dB, BGA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1000 ~ 10000 :	0.40 / Piece
10000 ~ 100000 :	0.30 / Piece

PartNumber:: TPA2010D1YZFT

Brand:: Texas Instruments - TI | Pack: BGA | D/C: 13+

Availability:: Supply Ability: 1000000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-13

From Other Seller

Part Number:TPA2010D1YZFT
US $0.30 - 0.50
Quantity:

piece

Product Summary

The TPA2010D1YZFT is a 2.5-W mono filter-free class-D audio power amplifier. The TPA2010D1YZFT allows independent gain while summing signals from seperate sources, and has a low 36 μV noise floor, A-weighted. Features like 88% efficiency, –75-dB PSRR, improved RF-rectification immunity, and 8 mm2 total PCB area make the TPA2010D1YZFT class-D amp ideal for cellular handsets. A fast start-up time of 1 ms with minimal pop makes the TPA2010D1YZFT ideal for PDA applications. Applications are (1)maximum battery life and minimum heat; (2)personal navigation devices; (3)general portable audio devices; (4)linear vibrator drivers.

Parametrics

TPA2010D1YZFT absolute maximum ratings: (1)VDD Supply voltage In active mode: -0.3 V to 6 V; (2)VDD Supply voltage In SHUTDOWN mode: -0.3 V to 7 V; (3)VI Input voltage: -0.3 V to VDD + 0.3 V; (4)TA Operating free-air temperature: -40℃ to 85℃; (5)TJ Operating junction temperature: -40℃ to 150℃; (6)Tstg Storage temperature: -65℃ to 150℃; (7)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds YZF: 260℃; (8)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds YEF: 235℃; (9)RI Input resistor Gain ≤ 20 V/V (26 dB): 15 kΩ; (10)PSRR Power supply rejection ratio VDD = 2.5 V to 5.5 V: -55 dB; (11)|IIH| High-level input current VDD = 5.5 V, VI = 5.8 V: 100 μA; (12)f(sw) Switching frequency VDD = 2.5 V to 5.5 V: 200 to 300 kHz.

Features

TPA2010D1YZFT features: (1)Maximum Battery Life and Minimum Heat; (2)Only Three External Components; (3)Wafer Chip Scale Packaging (WCSP); (4)Optimized PWM Output Stage Eliminates LC Output Filter; (5)Internally Generated 250-kHz Switching Frequency Eliminates Capacitor and Resistor; (6)Improved PSRR (–75 dB) and Wide Supply Voltage (2.5 V to 5.5 V) Eliminates Need for a Voltage Regulator; (7)Fully Differential Design Reduces RF Rectification and Eliminates Bypass Capacitor; (8)Improved CMRR Eliminates Two Input Coupling Capacitors.
