TLV62080DSGT

TLV62080DSGT, synchronous step down Regulation converter, 7 V, 2 kV, 2 mm, SON

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1000 ~ 10000 :	0.40 / Piece
10000 ~ 100000 :	0.30 / Piece

PartNumber:: TLV62080DSGT

Brand:: Texas Instruments - TI | Pack: SON | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-14

From Other Seller

Part Number:TLV62080DSGT
US $0.30 - 0.50
Quantity:

piece

Product Summary

The TLV62080DSGT device is a synchronous step down Regulation converter with an input voltage range of 2.5V to 5.5V. The TLV62080DSGT focuses on high efficient step down conversion over a wide output current range. At medium to heavy loads, the converter operates in PWM mode and automatically enters Power Save Mode operation at light load currents to maintain high efficiency over the entire load current range. Applications are (1)Battery Powered Portable Devices; (2)Point of Load Regulators; (3)System Power Rail Voltage Conversion.

Parametrics

TLV62080DSGT absolute maximum ratings: (1)Voltage range at VIN, PG, VOS(2): –0.3 to 7 V; (2)Voltage range at SW(2)(3): –0.3 to (VIN + 0.3V)V; (3)Voltage range at FB(2): –0.3 to 3.6 V; (4)Voltage range at EN(2): –0.3 to (VIN + 0.3V)V; (5)ESD rating, Human Body Model: 2 kV; (6)ESD rating, Charged Device Model: 500 V; (7)Continuous total power dissipation: See Dissipation Rating Table; (8)Operating junction temperature range, TJ: –40 to 125 °C; (9)Operating ambient temperature range, TA: –40 to 85 °C; (10)Storage temperature range, Tstg: –65 to 150 °C.

Features

TLV62080DSGT features: (1)DCS-ControlTM Architecture for Fast Transient Regulation; (2)2.5V to 5.5V Input Voltage Range; (3)100% Duty Cycle for Lowest Dropout; (4)Power Save Mode for Light Load Efficiency; (5)Output Discharge Function; (6)Power Good Output; (7)Thermal Shutdown; (8)Available in 2x2mm 8-Pin SON Package; (9)For Improved Features Set, See TPS62080.
