TLV320AIC3101IRHBR

TLV320AIC3101IRHBR, low-power stereo audio codec, QFN, -0.3to 3.9V, 0.5W, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: TLV320AIC3101IRHBR

Brand:: Texas Instruments - TI | Pack: QFN | D/C: 13+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-07-26

From Other Seller

Part Number:TLV320AIC3101IRHBR
US $0.30 - 0.50
TLV320AIC3101IRHBR

US $1.50 - 3.25 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TLV320AIC3101IRHBR is a low-power stereo audio codec with stereo headphone amplifier, as well as multiple inputs and outputs that are programmable in single-ended or fully differential configurations Extensive register-based power control is included, enabling stereo 48-kHz DAC playback as low as 14mW from a 3.3V analog supply, making the TLV320AIC3101IRHBR ideal for portable battery-powered audio and telephony applications. The applications of the TLV320AIC3101IRHBR include Digital Cameras, Smart Cellular Phones.

Parametrics

TLV320AIC3101IRHBR absolute maximum ratings: (1)AVDD to AVSS, DRVDD to DRVSS: –0.3 to 3.9 V; (2)AVDD to DRVSS: –0.3 to 3.9 V; (3)IOVDD to DVSS: –0.3 to 3.9 V; (4)DVDD to DVSS: –0.3 to 2.5 V; (5)AVDD to DRVDD: –0.1 to 0.1 V; (6)Digital input voltage to DVSS: –0.3 to IOVDD + 0.3 V; (7)Analog input voltage to AVSS: –0.3 to AVDD + 0.3 V; (8)Operating temperature range: –40 to 85℃; (9)Storage temperature range: –65 to 105℃; (10)TJ Max Junction temperature: 105℃; (11)Power dissipation: 0.5 W; (12)RθJA Thermal impedance: 44℃/W.

Features

TLV320AIC3101IRHBR features: (1)Stereo Audio DAC; (2)Six Audio Input Pins; (3)Stereo Fully Differential or Single-Ended Headphone Drivers; (4)Fully Differential Stereo Line Outputs; (5)Low Power; (6)Ultralow-Power Mode With Passive Analog Bypass; (7)Programmable Input/Output Analog Gains; (8)Automatic Gain Control (AGC) for Record; (9)Programmable Microphone Bias Level; (10)Programmable PLL for Flexible Clock Generation; (11)Extensive Modular Power Control.
