TLV1117LV25DCYR

TLV1117LV25DCYR, positive low-dropout voltage regulator, TO, 16V, 0.8A, Texas Instruments

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	0.50 / Piece
1001 ~ 10000 :	0.40 / Piece
10001 ~ 100000 :	0.30 / Piece

PartNumber:: TLV1117LV25DCYR

Brand:: Texas Instruments - TI | Pack: SOT | D/C: 13+

Availability:: Supply Ability: 100000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-17

From Other Seller

Part Number:TLV1117LV25DCYR
US $0.30 - 0.50
Quantity:

piece

Product Summary

The TLV1117LV25DCYR is a positive low-dropout voltage regulator designed to provide up to 800 mA of output current. The TLV1117LV25DCYR is available in 1.5-V, 1.8-V, 2.5-V, 3.3-V, 5-V, and adjustable-output voltage options. All internal circuitry is designed to operate down to 1-V input-to-output differential. Dropout voltage is specified at a maximum of 1.3 V at 800 mA, decreasing at lower load currents. The low-profile surface-mount KTP package allows the device to be used in applications where space is limited. The TLV1117LV25DCYR is designed to be stable with tantalum and aluminum electrolytic output capacitors having an ESR between 0.2 W and 10 W.

Parametrics

TLV1117LV25DCYR absolute maximum ratings: (1)VI, Continuous input voltage: 16 V; (2)TJ, Operating virtual-junction temperature: 150℃; (3)Tstg, Storage temperature range: -65 to 150℃.

Features

TLV1117LV25DCYR features: (1)1.5-V, 1.8-V, 2.5-V, 3.3-V, 5-V, and Adjustable-Output Voltage Options Levels; (2)Specified Dropout Voltage at Multiple Current; (3)Output Current of 800 mA; (4)0.2% Line Regulation Maximum; (5)0.4% Load Regulation Maximum.
