THS7373IPWR

THS7373IPWR, four-channel integrated video buffer, 5.5 V, ±90 mA, 6-dB,TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 500 :	3.00 / Piece
501 ~ 1000 :	2.00 / Piece
1001 ~ 3000 :	1.00 / Piece

PartNumber:: THS7373IPWR

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 13+

Availability:: Supply Ability: 1/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. mona cao's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-06-02

From Other Seller

Part Number:THS7373IPWR
US $1.00 - 3.00
Quantity:

piece

Product Summary

The THS7373IPWR is a low-power, single-supply, 3-V to 5-V, four-channel integrated video buffer. It incorporates one standard-definition (CVBS) and three high-definition (HD) filter channels. All filters feature sixth-order Butterworth characteristics that are useful as digital-to-analog converter (DAC) reconstruction filters or as analog-to-digital converter (ADC) anti-aliasing filters. The HD filters can be bypassed to support 1080p60 video or up to quad extended graphics array (QXGA) RGB video. The applications of the THS7373IPWR are (1)Set Top Box Output Video Buffering; (2)PVR/DVDR/ BluRay Output Buffering; (3)Low-Power Video Buffering.

Parametrics

THS7373IPWR absolute maximum ratings: (1)Supply voltage, VS+ to GND: 5.5 V; (2)Input voltage, VI: –0.4 to VS+ V; (3)Output current, IO: ±90 mA; (4)Maximum junction temperature, any condition, TJ: +150℃; (5)Maximum junction temperature, continuous operation, long-term reliability, TJ: +125℃; (6)Storage temperature range, TSTG: –60 to +150℃; (7)Human body model (HBM): 2500 V; (8)ESD rating: Charge device model (CDM): 1000 V; (9)Machine model (MM): 200 V.

Features

THS7373IPWR features: (1)One SDTV Video Amplifier for CVBS Video; (2)Sixth-Order Low-Pass Filters; (3)Versatile Input Biasing; (4)Built-in 6-dB Gain (2 V/V); (5)+3-V to +5-V Single-Supply Operation; (6)Rail-to-Rail Output; (7)Low Total Quiescent Current: 16.2 mA at 3.3 V; (8)Disabled Supply Current Function: 0.1 μA; (9)Low Differential Gain/Phase: 0.15%/0.25°; (10)RoHS-Compliant Package: TSSOP-14.
