Product Summary
The TDE1707BFP is a 0.5A Integrated Power Switch with up to 48V Power supply capability. The TDE1707BFP is dedicated to proximity detectors, its internal +5V supply can be used to supply external circuits (See also AN495/0692). A signal of the TDE1707BFP is internally generated to block the In signal, and prevent activation of the output switch, as long as an abnormal condition is detected.
Parametrics
TDE1707BFP absolute maximum ratings: (1)VS, Supply Voltage: 50 V; (2)VSr, Supply Reverse Voltage: 50 V; (3)IO, Output Current: internally limited A; (4)Vreg, Regulated Voltage Pin: 0 to 7 V; (5)Vdelay, Delay Cap. Surce Pin: 0 to 5 V; (6)VO, Output Diff. Voltage: 55 V; (7)Vi, Input Voltage: -10 to 50 V; (8)Top, Operating Temperature Range: -25 to +85 ℃; (9)Tstg, Storage Temperature: -55 to 150 ℃; (10)Ptot, Power Dissipation: internally limited W; (11)E, Energy Induct. Load: 150 mJ.
Features
TDE1707BFP features: (1)0.5A OUTPUT CURRENT; (2)LOW SIDE OR HIGH SIDE SWITCH CONFIGURATION; (3)6V TO 48V SUPPLY VOLTAGE RANGE; (4)OVERLOAD AND SHORT CIRCUIT PROTECTIONS; (5)INTERNAL VOLTAGE CLAMPING; (6)SUPPLY AND OUTPUT REVERSAL PROTECTION; (7)THERMAL SHUTDOWN; (8)GND AND VS OPEN WIRE PROTECTION; (9)ADJUSTABLE DELAY AT SWITCH ON; (10)INDICATOR STATUS LED DRIVER; (11)+5V REGULATED AUX. VOLTAGE; (12)HIGH BURST IMMUNITY.
